FOG-Based North Seeking Gyroscope Accurate True North Finder for UAV Navigation

FOG-Based North Seeking Gyroscope Accurate True North Finder for UAV Navigation

Marka Adı:	1
Model Numarası:	NF701
Moq:	1
fiyat:	2000$
Ödeme Şartları:	L/C, D/P, T/T, Western Union
Tedarik Yeteneği:	500/ay

Ayrıntılı Bilgiler

Ürün Açıklaması

Ayrıntılı Bilgiler

Menşe yeri:

Ürün adı:

fiber optik jiroskop kuzey bulucu

Ürün adı:

fiber optik jiroskop kuzey bulucu

Ürün adı:

fiber optik jiroskop kuzey bulucu

North seeking accuracy (1σ):

≤ 0.3 ° (NF701A); ≤ 0.5 ° (NF701B)

yatay doğruluk:

≤ 0,05 °

çevre:

≤ 0.5 °

Arayüz:

RS422

Güç kaynağı:

DC 12V ~ 24V

Güç kaynağı:

DC 12V ~ 24V

Ağırlık:

≤ 2 kg

Ağırlık:

≤ 2 kg

Dimension:

115 × 90 × 110mm

Ambalaj bilgileri:

Sünger + karton

Yetenek temini:

500/ay

Vurgulamak:

FOG-based north seeking gyroscope

accurate true north finder

underground navigation gyro

Ürün Açıklaması

FOG-Based North Seeking Gyroscope - Accurate True North Finder for UAV Navigation

Product Specifications

Attribute	Value
Product Name	fiber optic gyroscope north finder
North seeking accuracy (1σ)	≤ 0.3 ° (NF701A); ≤ 0.5 ° (NF701B)
Horizontal accuracy	≤ 0.05 °
Circumference	≤ 0.5 °
Interface	RS422
Power supply	DC 12V ~ 24V
Weight	≤ 2 kg
Dimension	115 × 90 × 110mm

Product Overview

The Fiber Optic Gyroscope North Finder provides rapid, autonomous determination of true north using advanced FOG technology. It measures the Earth's rotation to deliver high-precision azimuth and attitude information for UAVs, autonomous vehicles, robotics, marine vessels, and GPS-denied navigation systems.

Featuring an all-solid-state design with no moving parts, it ensures high reliability, long operational life, and low maintenance. Its compact, lightweight, and low-power construction allows seamless integration into dynamic platforms while maintaining fast alignment, stable performance, and robust resistance to harsh environments.

Technical Features

Fast operation: North seeking time ≤ 3 minutes
High precision: North seeking accuracy ≤ 0.3° (NF701A model)
Stable performance: Horizontal accuracy ≤ 0.05°
Compact design: Weighs ≤ 2 kg with dimensions of 115 × 90 × 110mm
Versatile power: Operates on DC 12V ~ 24V with peak consumption of 15W
Reliable interface: RS422 communication protocol
Automated operation: Self-check upon power-on with upper computer control

Environmental Specifications

Operating temperature: -40℃ to +70℃
Storage temperature: -55℃ to +85℃
Humidity resistance: Operates in relative humidity < 95%
Durable construction: Rust-free metal surfaces with intact coatings

Product Diagram

Fiber optic gyroscope north finder

Technical diagram showing dimensions and components
